Hustler Super 104-104"

  • Hustler Super 104 104
  • Hustler Super 104 104
  • Hustler Super 104 104
  • Hustler Super 104 104
  • Hustler Super 104 104
 Get Financed
Overview
Overview
104 Inch Width Of Cut Makes Big Jobs Easy.

Hustler's Super 104™ can easily handle acres of work. Offering a 104" width of cut, zero-turn precision and up to an impressive 11 mph speed, this machine is in a class by itself.

  • 38.5 - 40hp Vanguard & Kawasaki Engines

  • 104" deck

  • Up to 11 mph mowing speed

  • 5 Year / 1200 Hour (First 2 Years No Hour Limit)
Engine

Deck Sizes

38.5HP - Kawasaki FX1000 EFI

104” RD

40HP - Vanguard BigBlock EFI w/ Oil Guard

104” RD
Specifications
Model
Super 104
Category Name
Zero Turn Mowers
Year
2025
Sale Type
New
Manufacturer
Hustler
Quantity
0
Manufacturer Qty
0
features

Hustler Super 104 104

Unmatched Comfort

I3M suspension seat with 3-inch travel range.

Hustler Super 104 104

HyperDrive Hydro System

A Hustler® exclusive, industrial pumps and high torque wheel motors, 3-gallon reservoir, oil cooler and hot oil shuttle.

Hustler Super 104 104

104" Width of Cut

The widest and most productive of any commercial zero-turn mower.

Hustler Super 104 104 Wings Fold To 80"

80" transport width fits most trailers for easy travel between jobs.
key specs
WARRANTY
5 Year / 1200 Hour (First 2 Years No Hour Limit)
DRIVE_TIRE
26 x 12-12
FRONT_TIRE
15 x 6-6
TRANSMISSION
Danfoss DDC20 pumps with Parker TG wheel motors
CUTTING_WIDTH
104"
FUEL_CAPACITY
12 gal.
CUTTING_HEIGHT
1" to 5.5"
ENGINE_HORSEPOWER
40, 38.5
GROUND_SPEED_(FWD)
Up to 11 mph
ENGINE_MANUFACTURER
Vanguard BigBlock EFI Oil Guard, Kawasaki FX1000 EFI
engine
COOLING
Air Cooled
AIR_CLEANER
Remote Canister
DISPLACEMENT
993cc (Vanguard), 999cc (Kawasaki)
ENGINE_WARRANTY
3 year warranty
ENGINE_HORSEPOWER
40, 38.5
ENGINE_MANUFACTURER
Vanguard BigBlock EFI Oil Guard, Kawasaki FX1000 EFI
drive system
TYPE
Dual Hydrostatic
TRANSMISSION
Danfoss DDC20 pumps with Parker TG wheel motors
FUEL_CAPACITY
12 gal.
PARKING_BRAKE
Integrated with steering levers
HYDRAULIC_COOLING
Oil Cooler w/9" fan
GROUND_SPEED_(FWD)
Up to 11 mph
RESERVOIR_CAPACITY
3 gallons
deck
SPINDLES
Ductile cast iron with steel shaft and sealed ball bearings
DECK_LIFT
Hydraulic powered
DECK_DEPTH
5.5"
BLADE_LENGTH
23.86" - 20.5"
CUTTING_WIDTH
104"
DECK_MATERIAL
11 gauge welded steel
CUTTING_HEIGHT
1" to 5.5"
SPINDLE_MOUNTS
Reinforced 7 ga doubler
BLADE_TIP_SPEED
Wing Decks: 15,800; Center Deck: 15,500
DECK_ENGAGEMENT
Electric PTO Clutch
IMPACT_TRIM_AREA
1.5" x .375" steel bar
NUMBER_OF_BLADES
5
construction
FRAME
1.5" X 3" steel tubing
FRONT_AXLE
Fabricated w/ tapered roller bearings
FRONT_CASTER_FORK
Fabricated 1/2" steel
FRONT_CASTER_WHEEL
Tapered wheel bearings and debris cap
general
SEAT
I3M Suspension Seat (adjustable armrests & back)
CUP_HOLDER
dimensions
WEIGHT_(LBS)
2500
HEIGHT_(INCHES)
54" (71.5" w/ ROPS)
LENGTH_(INCHES)
95.5"
WING_TIRE_(INCHES)
11 x 4 semi-pneumatic
DRIVE_TIRE_(INCHES)
26 x 12-12
FRONT_TIRE_(INCHES)
15 x 6-6
WIDTH_W/_CHUTE_UP_(INCHES)
106.1 wings down, 80" wing up at gauge wheel, 72.5" wings up at deck base
TIRE-TO-TIRE_WIDTH_(INCHES)
60.3
PRODUCTIVITY_(ACRES_PER_HOUR)
9.24
literature
Name Link
Specs PDF Download
Brochure PDF Download
warranty
Warranty
5 Year / 1200 Hour (First 2 Years No Hour Limit)
